Designed, engineered and made in France, the Elipson Connect 2130 Xi – is a hi-res streaming amplifier.
The Elipson Connect 2130 Xi amplifier has a built-in streamer, Bluetooth 5.1, WiFi and LAN connectivity, as well as AirPlay 2, Chromecast, UPnP and DLNA functionality, allowing users to stream their favourite music in high quality, wirelessly. Line-in and RCA inputs offer the flexibility for connecting a variety of audio sources, while the subwoofer output provides an additional option for boosting low frequencies.
Adapted to the needs of installers the Connect 2130 Xi is equipped with Class D amplification, delivers 2 x 130W of power and a PFC power factor correction system for optimum regulation of the power supplied, whatever the mains voltage, offering harmonic distortion of less than 0.003% and a signal-to noise ratio of more than 119 dB.
It can be activated in mono mode, delivering 250W RMS and 500W peak at 8 ohms. It is also compatible with 100V loudspeakers for sound reinforcement in large spaces. With compact dimensions of 215 x 44.5 x 220 mm and a weight of just 2 kg, the Elipson Connect 2130 Xi amplifier fits easily into any professional environment. In addition, an optional rack-mountable front panel allows 2 Connect 2130 Xi to be integrated, providing a neat installation in a standard rack.
The product is rackable (1U dimensions) with an optional front panel, output settings breakdown into stereo/mono-bridge /100V. In-out trigger (5 – 12V) is also included.
Connectivity and Streaming
The Elipson Connect 2130 Xi connects to the Internet via Wi-Fi or Ethernet, giving access to streaming services such as Spotify, Deezer, Tidal, Qobuz and Amazon Music, as well as iHeartRadio and TuneIn. Its ESS SABRE ES9023 DAC supports high-resolution formats up to 24 bits / 192 kHz, offering strong audio quality. With integrated AirPlay 2, Chromecast and Bluetooth 5.1, owners can stream music from any device. The multi-room functionality allows customers to create a homogenous musical ambience in each room. Commercial access to the product is managed by Avoke Ltd.
Product Details
Type – Compact connected amplifier (low impedance mode – 100V)
Technology – Class D
Power – 2 x 130 W RMS @ 4 & 8 Ω
Power bridge mode into 8 Ω – 250 W RMS / 500 W peak
Harmonic distortion (THD) @ 1 W – < 0,003 %
Frequency response – 20 Hz – 50 kHz
Signal-Noise ratio – 119 dBA
Damping factor – 350
Inputs
• Unbalanced RCA
• HDMI ARC
• Bluetooth 5.1
LAN network
• Wi-Fi 2.4 GHz / 5 GHz 802.11 b/g/n/ac
• Ethernet RJ-45
Bitrate / DAC Chip – Hi-Res : 24 Bit – 192 kHz / ESS SABRE ES9023
Streamer
• AirPlay 2
• Chromecast built-in™
• UPnP
• DLNA
Applications
• WiiM APP (supports Android/iOS system)
• Spotify, Deezer, Qobuz, Amazon Music,Audirvana, Tidal, Tunein etc.
Output configuration – Stereo / Bridge mono / 100V
Trigger – IN & OUT (5 – 12V)
Led – Clipping and protection
Max temperature – 40° C (fan automatic trigger)
